Swarovski TM35 Hand-Held/Clip-On Thermal (320x256) Imaging Device - Black

Swarovski TM35 Hand-Held/Clip-On Thermal (320x256) Imaging Device. Featuring state-of-the-art thermal imaging technology, the tM 35 impresses both as a thermal imaging hand-held device and as a thermal imaging clip-on device. The proven, energy-saving SWAROLIGHT automatic switch-on/off timer and intelligent brightness adjustment ensure it is ready for use at all times. Depending on the hunting situation, detail recognition can be enhanced by switching between White Hot and Black Hot mode. The tM 35 can be operated intuitively in darkness and is compatible with SWAROVSKI OPTIK rifle scopes from the Z8i, Z6i, Z5(i), and Z3 series.

FOR THE MANY SIDES OF THE NIGHT
With the tM 35, hunters can count on proven SWAROVSKI OPTIK quality. A thermal imaging observation and clip-on device with modern thermal imaging technology in one, for impressive enhanced vision and responsible hunting at dark.

A SURE SHOT IN DARKNESS
As a thermal imaging clip-on device with 1x magnification, the tM 35 impresses with its absolute accuracy. Together with your SWAROVSKI OPTIK rifle scope, it forms a reliable, complete system that requires no sighting in. The conical shape allows straightforward placement on the rifle scope in darkness.

READY WHEN YOU ARE
Avoid irritating distractions and focus entirely on the essentials: The intelligent SWAROLIGHT automatic switch-on/off timer with tilt sensor allows you to activate the thermal imaging device silently from sleep mode with no unnecessary movements.

IN HARMONY WITH THE NIGHT
The brightness of the display is automatically adjusted to the prevailing light conditions. This avoids dazzling and the resulting temporary impairment of vision.

THE NIGHT IN YOUR SIGHTS
The tM 35 allows you to detect game even at long distances. As a hand-held device, it impresses with 4x magnification. Making sure you don’t miss any details in darkness or adverse weather.

EYES FOR THE NIGHT
Nature reveals its special magic after dark. When it seems like everything is asleep and you’re all alone in nature, that’s when you need to be particularly alert. Changing conditions, such as increasing instances of game damage and illnesses, mean that hunting now more frequently needs to continue late into the night.

Specifications

OBJECTIVE

• Field of view: 10.9x8.7 m/100m
• Field of view with eye glasses (%): 100 %
• Exit pupil distance (4x magnification): 21 mm
• Optical magnification: 1x
• Digital magnification: 4x
• Objective lens: 35 mm/f1.1

SIZE & WEIGHT

• Length in mm: 170 mm
• Width in mm: 54 mm
• Height in mm: 80 mm
• Weight: 495 g
• Connection thread: M44x0.75

ENVIRONMENT & CONDITIONS

• Functional temperature: -15 to +50 °C
• Storage temperature: -30 to +70 °C
• IP protection class: IP68

DIGITAL

• Refresh rate (Hz): 60Hz
• Screen type: AMOLED
• Screen resolution (pixels): 2560x2048
• Sensor type: Uncooled VOx microbolometer
• Sensor resolution (pixels): 320x256
• Pixel size (µm): 12
• Start up time (s): 2 s

BATTERY

• Battery: Li-lon 3000 mAh
• Battery operating time during normal / maximum operation: 7 h
