HIKMicro Lynx 3.0 LQ35L Thermal (640x512) Monocular w/LRF

HIKMICRO Lynx 3.0 LQ35LRF Thermal Monocular

Craftsmanship & Construction

The Lynx 3.0 LQ35LRF is engineered around a VOx uncooled focal plane array sensor, delivering a high-resolution thermal image with a smooth 50Hz refresh rate. Its 35mm F1.0 lens supports strong thermal sensitivity and long-range detection, while the integrated laser rangefinder adds an additional layer of functionality for distance measurement.

The device features a compact and robust housing, weighing approximately 354.5g and designed for durability in field conditions. Its sealed construction is rated to IP67, providing protection against dust and water ingress.

Fit & Comfort

Designed for handheld operation, the monocular incorporates a focus ring for precise manual adjustment and a comfortable viewing experience. The 0.49-inch AMOLED display with 1920 × 1080 resolution delivers clear and detailed visuals, supported by a 20mm eye relief and adjustable diopter range from -5D to +3D.

Its lightweight and pocket-sized design ensures ease of carry and extended usability without unnecessary bulk.

Waterproof Performance

The Lynx 3.0 LQ35LRF features an IP67 protection rating, ensuring reliable performance in wet and dusty environments. This level of sealing allows for consistent operation across a wide range of outdoor conditions.

Key Features

• 640 × 512 thermal resolution with VOx uncooled sensor
• Integrated laser rangefinder for precise distance measurement
• 35mm F1.0 lens with detection range up to 1800 metres
• NETD less than 15 mK for enhanced thermal sensitivity
• 1.9x to 15.2x magnification range
• 1920 × 1080 AMOLED display
• HIKMICRO Shutterless Imaging System (HSIS)
• Image Pro 3.0 and Zoom Pro image enhancement technologies
• Multiple colour palettes including Black Hot and White Hot
• Built-in 64GB memory with video, image, and audio recording
• Wi-Fi hotspot connectivity (2.4 GHz / 5 GHz)
• Replaceable and rechargeable 18650 battery

Materials & Care

The monocular is constructed with durable electronic and optical components within a sealed body designed for outdoor use. Care involves keeping the lens clean and dry, storing the device appropriately, and maintaining the rechargeable battery in line with standard usage practices.

Specifications

• Sensor: VOx Uncooled Focal Plane Array
• Resolution: 640 × 512
• Frame Rate: 50 Hz
• Lens: 35mm, F1.0
• Detection Range: Up to 1800 m
• Magnification: 1.9x – 15.2x
• Field of View: 12.5° × 7.5°
• Display: 0.49-inch AMOLED, 1920 × 1080
• Battery Life: Up to 5 hours (25°C), 4.5 hours (-20°C)
• Memory: 64GB built-in
• Protection Rating: IP67
• Weight: Approximately 354.5 g

HIKMICRO Lynx 3.0 LQ35LRF Thermal Monocular Review

The HIKMICRO Lynx 3.0 LQ35LRF Thermal Monocular is designed for users who require both advanced thermal imaging and accurate distance measurement in a single compact device. Its high-resolution sensor and extended detection range make it well suited for professional field use.

The addition of a built-in laser rangefinder enhances its practicality, offering greater precision when identifying and assessing targets at distance.

HIKMICRO Lynx 3.0 LQ35LRF Thermal Monocular Performance & Key Features

This model delivers strong imaging performance combined with added functionality from the integrated laser rangefinder.

• 640 × 512 sensor provides detailed thermal imaging
• Laser rangefinder enables accurate distance measurement
• Detection range up to 1800m supports long-range use
• Image Pro 3.0 improves clarity and contrast
• Shutterless imaging ensures uninterrupted viewing

Build Quality & Handling

The monocular features a durable, compact design that supports reliable use in outdoor environments. Its IP67 rating ensures protection from dust and water, while the lightweight construction allows for comfortable handheld operation.

The integrated rangefinder does not significantly impact handling, maintaining a balanced and portable form.

Is the HIKMICRO Lynx 3.0 LQ35LRF Thermal Monocular Easy to Use?

The device is designed for straightforward operation, with intuitive controls and clear visual feedback through the AMOLED display. The focus ring and diopter adjustment allow users to quickly refine the image to suit their preferences.

• Simple focus adjustment via manual focus ring
• Clear and responsive AMOLED display
• Integrated rangefinder adds functionality without complexity
• Built-in recording and connectivity features enhance usability

Key Takeaways of the HIKMICRO Lynx 3.0 LQ35LRF Thermal Monocular

The Lynx 3.0 LQ35LRF combines high-resolution thermal imaging with the practical advantage of an integrated laser rangefinder, making it a versatile tool for demanding field applications. Its lightweight yet durable design supports use in varied environments, while advanced imaging technologies ensure consistent performance. Battery life is moderate depending on conditions, but the replaceable battery design adds flexibility. It is well suited to experienced users seeking both observation and distance measurement in a single device.

HIKMICRO Lynx 3.0 LQ35LRF Thermal Monocular FAQs

Does the HIKMICRO Lynx 3.0 LQ35LRF include a laser rangefinder?

Yes, this model features an integrated laser rangefinder, allowing users to measure distances accurately during observation.

What is the detection range of the Lynx 3.0 LQ35LRF?

The monocular offers a detection range of up to 1800 metres, making it suitable for long-range observation in open environments.

What magnification range does this thermal monocular provide?

It offers a magnification range from 1.9x to 15.2x, providing flexibility for both wide-area scanning and detailed observation.

Is the device suitable for use in wet or dusty conditions?

With an IP67 protection rating, the monocular is resistant to dust and water ingress, supporting reliable use in challenging outdoor environments.

What type of display does the Lynx 3.0 LQ35LRF use?

The device features a 0.49-inch AMOLED display with a resolution of 1920 × 1080 for clear and detailed viewing.

Can it record images and video?

Yes, it supports video recording, snapshot capture, and audio recording, all stored on the built-in 64GB memory.

What is the battery performance like?

The device offers up to 5 hours of continuous operation at 25°C and approximately 4.5 hours at -20°C using a replaceable 18650 battery.

Does it support wireless connectivity?

Yes, it includes Wi-Fi hotspot functionality supporting both 2.4 GHz and 5 GHz bands for connectivity and data sharing.

What is the field of view?

The monocular provides a field of view of 12.5° × 7.5°, allowing effective scanning of wider areas.
